Fast 90C
Breathing Air Compressors
High pressure breathing air compressors for fire fighting, scuba diving, oil patch breathing air, homeland security teams, haz-mat response teams, for industrial breathing air users, laboratory breathing air, commercial diving, and paintball cylinder refilling. Airworks offers a proven and economical compressor for all these applications.
For fire departments, we can stop your running across the county to get your SCBA and SCUBA cylinders refilled! Our dependable HP compressors provides you with CGA grade E breathing air, without having to rob a bank to pay for it. We are proud to offer the American Airworks Fast series of HP breathing air compressors.
User friendly features included for a great value at a low price.
|
|
|
|
 |
|
High Pressure Breathing Air Compressor
(3 phase cabinets are rectangular)
|
|
|
|
Delivers 9 CFM NFPA Grade E breathing air at 5000 PSI
Delivers 8 CFM NFPA Grade E breathing air at 6000 PSI
|
|
|
|
Our Fast 90C breathing air compressors provide 5000 PSI and 6000 PSI breathing air. The Fast90C breathing air compressor is compact in size, very user friendly and our most popular model. This compressor is great for the small to mid-sized fire departments, fire brigades, dive shops and paintball fields. Complete with a 9000 CF cartridge purification chamber. We have packed this HP compressor with many standard features that others charge extra for. The Fast 90C is a continuous duty compressor. Click here for a compressor quote.
Standard Air Compressor features include:
- Automatic moisture drain and reservoir
- Dial-A-Pressure gauge (click here for photo)
- Interstage Pressure Gauges
- Visual oil level gauge (click here for photo)
- High Temperature Shutdown Switch
- Low oil level switch
- CO/H2O Visual Air Line Module (Blue/Tan OK - Pink/Brown = Change Filter)
- Magnetic Motor Starter
- Hour meter
- Sound Dampening Cabinet
6000 PSI
Specifications for Fast90C 6000 PSI Breathing Air Compressor
AC95591-6M - 6000 PSI 7.5 HP E-1 230v 60Hz Single Phase 9,000 CF Purification
$13,275
AC95593-6M - 6000 PSI 7.5 HP E-3 230v 60Hz Three Phase 9,000 CF Purification
$12,850
AC95591-6M26 - 6000 PSI 7.5 HP E-1 230v 60Hz Single Phase 26,000 CF Purification
$14,275 - (Has purification filter upgrade added)
AC95593-6M26 - 6000 PSI 7.5 HP E-3 230v 60Hz Three Phase 26,000 CF Purification
$13,850 - (Has purification filter upgrade added)
Breathing Air Compressor Options - Fast 90 Compact
|
Part Number
|
Description
|
Price
|
|
AC95591B
|
Compressor Stand - Aluminum Treadplate
|
$269.00
|
|
AC95591C
|
Compressor Cover - Coated Blue Bradish Cloth
|
$172.00
|
|
AC95590
|
Inlet Filter - Disposable
|
$19.50
|
|
AC95601
|
Purification Filter - 9000 CF - Disposable
|
$60.20
|
|
AC95512
|
Purification Filter - 26000 CF - Disposable
|
$82.04
|
|
AC95510
|
Purification Tower Upgrade to 26,000 CF Capacity (Pays for itself on replacement filter purchases)
|
$1095.00
|
|
AC99050
|
Synthetic Ester Grade Oil (1 Gal) 300º Boiling Point
|
$50.00
|
|
AC99050-FG
|
Synthetic Food Grade Oil (1 Gal) 570º Boiling Point
|
$53.00
|
|
AC95570
|
CO/H2O Moisture Visual Element Only
|
$22.50
|
|
AC95566
|
|
$5575.00
|
|
AC95566-1
|
AirCal 1000 Electronic CO Monitor
|
$4375.00
|
|
AC41000-E1
|
|
$96.25
|
** Filter upgrade (AC95510) required to tall tower use the AirCal 2000 monitor
|
|
|
|
Fast 90 Portable Breathing Air Compressors |
|
|
Portable high pressure breathing air compressors for your mobile breathing air applications. Our Fast 90 portable breathing air compressors provides 9 CFM 5000 PSI of CGA Grade E breathing air. This three stage basic compressor is compact in size and very user friendly. Purification cartridge provides 9000 CF of breathing air @ 70 degrees ambient air temperatures. This is a continuous duty compressor.
Standard features include:
- Magnetic Motor Starter (not included by many vendors - $375 savings)
- Manual Moisture Drains
- Final Pressure Gauge
- Hour Meter (not included by many vendors - $75 savings)
AC95595 - 5000 PSI 7.5 HP E-1 230v 60Hz 1 Phase
$8,645
AC95597 - 5000 PSI 7.5 HP E-3 230v 60Hz 3 Phase
$8,480
AC95592 - 5000 PSI Honda 9.0 HP Gas Engine
$8,585
AC95598 - Yanmar 9.0 HP Diesel Engine
$9,703
Select Fill Hose from Optional Items below.
|
|
|
|
 |
|
AC95597
|
|
 |
|
AC95592
|
|
|
|
Fast 90 Portable Breathing Air Compressor Options |
|
|
|
Part Number
|
Description
|
Price
|
|
AC95566-1
|
AirCal 1000 Electronic CO Monitor
|
$4375.00
|
|
AC95501
|
Automatic Condensate Drain with Timer*
|
$990.00
|
| AC95514 |
Auto Stop Pressure Switch for Electric & Gas Units* |
$195.00 |
|
AC95506
|
Interstage Pressure Gauges
|
$330.00
|
| AC95590 |
Inlet Filter - Disposable |
$19.50 |
| AC95601 |
Purification Filter - 9000 CF -Disposable |
$60.20 |
|
AC95512
|
Purification Filter - 26000 CF -Disposable
|
$82.00
|
|
AC99050
|
Synthetic Ester Grade Oil (1 Gal) 300º Boiling Point
|
$50.00
|
|
AC99050-FG
|
Synthetic Food Grade Oil (1 Gal) 570º Boiling Point
|
$53.00
|
|
AC95504
|
Visual Air Line Monitor Module - CO/H20 Moisture
|
$130.00
|
| AC95570 |
CO/H2O Moisture Visual Element Only |
$22.50 |
|
AC41000-E1
|
|
$96.25
|
|
AC10026
|
5' SCBA Fill Hose Assembly
|
$245.00
|
|
AC10026-PB
|
5' Paintball Fill Hose Assembly
|
$245.00
|
|
AC10026-SC
|
5' SCUBA Fill Hose Assembly
|
$245.00
|
|
|
|
|
|
Portable high pressure breathing air compressors for your mobile breathing air applications. The electric model is a good mid-range CFM compressor that works great for smaller fire departments, dive boats, paintball users and fields and diving applications. Our Fast 50 portable breathing air compressors provide 5000 PSI breathing air. Delivers 5.5 CFM of Grade E breathing air. This three stage compressor uses the same crankcase as the 90 and slightly smaller piston-cylinders to provide a very durable and user friendly compressor.
The standard features include manual moisture drains, hour meter, outlet pressure gauge. Complete with a 9000 CF cartridge purification filtration chamber. Filtration system provides grade E breathing air for SCBA and SCUBA use. This is a continuous duty compressor.
|
|
|
|
 |
|
AC95551
|
|
|
|
|
Standard features include:
- Magnetic Motor Starter (not included by many vendors - $375 savings)
- Manual Moisture Drains
- Final Pressure Gauge
- Hour Meter (not included by many vendors - $75 savings)
AC95555 - Honda 6.5 HP Gas
$7,720
AC95551 - 5 HP E-1 230v 60Hz 1 Phase
$7,915
AC95553 - 5 HP E-3 230v 60Hz 3 Phase
$7,915
Select Fill Hose From Optional Items Below.
|
|
|
| Portable Breathing Air Compressor Options - Fast 50 |
|
|
|
Part Number
|
Description - Electric Model Only
|
Price
|
|
AC95566-1
|
AirCal 1000 Electronic CO Monitor
|
$4375.00
|
|
AC95504
|
Visual Moisture/CO Air Line Indicator
|
$130.00
|
|
AC95506
|
Interstage Pressure Gauges
|
$330.00
|
|
AC95501
|
Automatic Condensate Drain with Timer*
|
$990.00
|
| AC95514 |
Auto Stop Pressure Switch for Electric & Gas Units* |
$195.00 |
| AC95601 |
Purification Filter - 9000 CF -Disposable |
$60.20 |
| AC95590 |
Inlet Filter - Disposable |
$19.50 |
| AC95570 |
Element Only - CO/H2O Moisture |
$22.50 |
| AC99050 |
Synthetic Ester Grade Oil (1 Gal) 300º Boiling Point |
$50.00 |
|
AC99050-FG
|
Synthetic Food Grade Oil (1 Gal) 570º Boiling Point
|
$53.00
|
|
AC41000-E1
|
|
$96.25
|
|
AC10026
|
5' SCBA Fill Hose Assembly
|
$245.00
|
|
AC10026-PB
|
5' Paintball Fill Hose Assembly
|
$245.00
|
|
AC10026-SC
|
5' SCUBA Fill Hose Assembly
|
$245.00
|
|
|
| Fast 35 Portable Breathing Air Compressors |
|
|
Load the Fast35 air compressor in the truck, van or car trunk and you're off to have fun and not worry about where to get air.
The American Airworks Fast 35 Portable is a reliable personal four stage high pressure breathing air compressor capable of 4500 PSI. Delivers 3.5 CFM of Grade E breathing air. Ideal for location dives, pleasure boats, paintball users, laboratory applications requiring high pressure breathing air or wherever portability, space and weight are considerations. Provides approximately 3200 CF of purification. Easy to operate and maintain.
The Fast 35 will provide years of high quality breathing air in locations where air stations are not accessible. This is not a continuous duty compressor. It is not designed for refilling large storage cylinders.
Standard features include:
- Manual Moisture Drains
- Final Pressure Gauge
- Hour Meter (not included by many vendors - $75 savings)
- Fill Hose for either SCUBA, Paintball or SCBA
AC95535 - 4500 PSI Honda 5.5 HP Gas
$3190
AC95534 - 4500 PSI 3 HP, E-1 230v 60Hz
$3190
AC95533 - 4500 PSI 4 HP, E-3 230 60Hzv
$3190
Free Speedy Shipping in 48 state included within this price.
|
|
|
|
|
|
This Fast 35 unit is identical to the unit show above but has our deluxe cabinet. An optional refill toggle valve is shown below, on the unit, and is available to speed up the refill process.
|
|
AC95535-C - 4500 PSI Honda 5.5 HP Gas
$3340
AC95534-C - 4500 PSI 3 HP, E-1 230v 60Hz
$3340
AC95533-C - 4500 PSI 4 HP, E-3 230 60Hzv
$3340
Free Speedy Shipping in 48 state included within this price. |
|
 |
|
|
|
Fast 35 Portable Breathing Air Compressor Options |
|
|
|
|
Part Number
|
Description
|
Price
|
| AC95514 |
Auto Stop Pressure Switch for Electric & Gas Units |
$195.00 |
|
AC95536
|
Deluxe Paintball Toggle Fill Control
|
$275.00
|
|
AC95541
|
Inlet Filter - Disposable
|
$19.50
|
| AC95540 |
Purification Filter Cartridge - 3200 CF - Disposable |
$39.90 |
|
AC99050
|
Synthetic Ester Grade Oil (1 Gal) 300º Boiling Point
|
$50.00
|
|
AC99050-FG
|
Synthetic Food Grade Oil (1 Gal) 570º Boiling Point
|
$53.00
|
|
AC95504
|
Visual Moisture/CO Air Line Indicator
|
$130.00
|
| AC95570 |
CO/H2O Moisture Visual Element Only |
$22.50 |
|
AC41000-E1
|
|
$96.25
|
|
|
|
|
|
|
 |
|
Used Breathing Air Compressors For Sale...
Click Here
Click here to see some of our present stock of used compressors. If we don't have it, we have a network of compressor distributors we can contact to help locate a compressor that will fit your needs and budget. Email us to register to receive notice of new used compressors.
|
|
|
 |
|
Purification Filters for all Breathing Air Compressors - At A Discount
Click Here for filters
Replacement purification breathing air filter cartridges to produce CGA Grade "E" breathing air.
|
|
|
 |
|
Air Quality Testing
Air quality testing meeting NFPA standards. NFPA mandates quarterly air testing of high pressure breathing air compressor owners.
American Airworks can set you up on a schedule where you receive your air sampling kit automatically. Choose annual, semiannually or quarterly.
|
P/N
|
Description
|
Price
|
|
AC41000-D1
|
Air Test Kit, Grade D, 1X
|
$90.31
|
|
AC41000-D2
|
Air Test Kit, Grade D, 2X
|
$171.53
|
|
AC41000-D4
|
Air Test Kit, Grade D, 4X
|
$324.45
|
|
AC41000-E1
|
Air Test Kit, Grade E, 1X
|
$96.25
|
|
AC41000-E2
|
Air Test Kit, Grade E, 2X
|
$182.77
|
|
AC41000-E4
|
Air Test Kit, Grade E, 4X
|
$345.54
|
|
AC41000-DN1
|
Air Test Kit, Grade D, 1X, NFPA 1500
|
$92.47
|
|
AC41000-DN2
|
Air Test Kit, Grade D, 2X, NFPA 1500
|
$175.74
|
|
AC41000-DN4
|
Air Test Kit, Grade D, 4X, NFPA 1500
|
$329.86
|
|
AC41000-EN1
|
Air Test Kit, Grade E, 1X, NFPA 1500
|
$97.34
|
|
AC41000-EN2
|
Air Test Kit, Grade E, 2X, NFPA 1500
|
$187.10
|
|
AC41000-EN4
|
Air Test Kit, Grade E, 4X, NFPA 1500
|
$355.81
|
Air sampling kits are easy to use and a computerized certificate is mailed to you showing your air purity. Order your kit today.
Get your air test kit today, call us at... 1-800-523-7222
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
